InfiRay M6T Mobile

• The Thermal PTZ (Pan-Tilt-Zoom) camera is a sophisticated thermal imaging system designed to be mounted on a vehicle for enhanced scanning and situational awareness during night operations. Main benefits include:
• Enhanced Night Visibility: Utilizes high-resolution thermal imaging (640×512 sensor resolution) to detect heat signatures in complete darkness or through obstructions like smoke and foliage.
• Long Detection Range: Capable of detecting objects up to 1375 yards away, making it ideal for surveillance, wildlife observation, and security applications.
• Onboard Recording: Features the capability to record video directly on the device, allowing users to review footage later.
• Gyro Stabilization: Ensures smooth and stable imagery even when the vehicle is in motion or in challenging environmental conditions.
• Mobile App Connectivity: Offers the convenience of wireless streaming and remote control via a mobile app, enhancing user experience and operational flexibility.
• Laser Rangefinder and Pointer: Equipped with an integrated laser rangefinder and pointer for precise targeting and measurement.
• Durability: Built to withstand years of use in harsh environments, thanks to its rugged aluminum housing and resistance to the elements.

InfiRay M6T Mobile Review

InfiRay M6T Mobile Features and Specs

The InfiRay Outdoor M6T Mobile Thermal PTZ 25mm LRF 640x480 12 Micron 25mm is a robust, state-of-the-art thermal imaging system designed for vehicle installation, providing unparalleled scanning capabilities in night hunting scenarios. It embodies a collection of advanced features aimed at delivering superior performance, including video recording, gyro stabilization, wireless streaming via mobile app connectivity, and integrated laser pointer and laser rangefinder for enhanced situational awareness. The system's durability ensures it withstands years of use and exposure to harsh environmental conditions. It comes complete with power and signal wiring harnesses, and an easy-to-use wired thumbstick controller for effortless pan and tilt navigation, enhancing any vehicle with powerful thermal imaging technology.

Key Features:

• Objective Focal Length: 25mm
• Digital and Optical Magnification: 4X and 1X respectively
• Objective Diameter: 25mm
• Detection Range: 1375 Yards
• Onboard Recording: Yes
• Connectivity: Wifi and Mobile App support
• User-Updatable Firmware: Yes
• Power Source: DC 12V
• Warranty: 5 years
• Physical Specifications: Weighs 70.5 Oz., with an aluminum housing material
• Sensor Specifications: Utilizes InfiRay MICRO II technology, with a resolution of 640×512, pixel size of 12μm, frame rate of 50hz, and thermal sensitivity less than 50mk.

What's in the box of the InfiRay M6T Mobile?

• InfiRay M6T Mobile Thermal PTZ camera system
• Wired thumbstick controller for pan and tilt control
• Power and signal wiring harnesses
• Integrated laser pointer and laser rangefinder
• Mobile app connectivity with wireless streaming capability
• Onboard video recording feature
• User manual for installation and operation

InfiRay M6T Mobile FAQs

Can the InfiRay M6T be mounted on any type of vehicle?

Yes, the InfiRay M6T is designed with versatility in mind. It comes with power and signal wiring harnesses that allow it to be installed on a wide range of vehicles. Please check the specific requirements in the manual to ensure compatibility with your vehicle.

How does the gyro stabilization feature improve the thermal imaging experience?

The gyro stabilization feature is crucial for reducing image blur and enhancing the clarity of thermal images, especially when the device is mounted on moving vehicles. It helps to stabilize the image, providing clearer and more accurate thermal readings while on the move.

Is it necessary to use the mobile app to control the iRay M6T Mobile, or can it be operated without it?

While the mobile app offers convenient control and additional features like wireless streaming, the M6T can also be operated using the included wired thumbstick controller. This allows users to pan, tilt, and adjust the camera without needing to use the mobile app.

Can the onboard recording feature be used without an external storage device?

Yes, the M6T includes onboard recording capabilities, allowing users to record thermal videos directly within the device. However, for extended recording or higher resolution videos, an external storage solution might be required.

How accurate is the laser rangefinder, and what range does it cover?

The integrated laser rangefinder in the M6T offers high precision measurement, with accuracy up to one meter, covering distances up to 1375 yards. This feature enhances situational awareness and helps in accurately gauging distances in various outdoor conditions.

Is there any special maintenance required to keep the iRay M6T operational over time?

To maintain optimal performance, it is recommended to regularly clean the lens and inspect the device for damage. Additionally, firmware updates should be installed as they become available to ensure access to the latest features and improvements.
